SEMI-AUTOMATIC Target Hole Drilling Machine KX-ZB2530

Product Specification:

Inquiry Now

These Machine accessories May you like

Product Details

Features

◆ Use High Precision HINWIN Linear Guide

◆ Spindle Speed 60000rpm /40000rpm

◆ Drilling Offset Accuracy Is ≤0.02mm

◆ Can Drilling Single Side,Double Side /Multi Layer PCB,MCPCB

Drilling Hole Dia	1.0-6.0 mm
Board Thickness	0.2-3.0mm
Drilling Precision:	Center deviation ≤0.03mm,Aperture deviation≤0.03mm
Drilling Speed	≤0.6s / Holes
Power:	220V±10% 1.5KVA
Air Pressure:	≥0.6mpa
Machine Size:	9008201180mm
Machine Weight:	200KG
Spindle Speed :	40000 RPM
Spindle Power	Spindle Power
Tool change way	Manual tool change
